Foggy picture...improvements possible??
Posted: October 13th, 2011, 7:32 am
by bbodine9
Just wondering if anyone can improve the foggy pictures on the attached link?
Link:
http://forums.dpreview.com/forums/read. ... e=39566029
Thanks in advance for the help / education
Re: Foggy picture...improvements possible??
Posted: October 13th, 2011, 8:37 am
by Dieter Mayr
A good help for foggy pictures is filtering the picture with itself.
Filter - Input Image and Filter the same image.
When it is just partially foggy like in the last image maybe a mask can help.
Re: Foggy picture...improvements possible??
Posted: October 13th, 2011, 11:55 am
by den
The histogram equalization and tone mapping of SNS-HDR Lite's 'default' preset followed by preference luminance noise reduction for the micro-contrast rending in the 'foggy' image areas could significantly improve this image set...
- SF_Osprey2-1.JPG (25.39 KiB) Viewed 6734 times
A SNS-HDR Lite & PWP discussion is here:
http://www.dl-c.com/board/viewtopic.php?f=4&t=398
Re: Foggy picture...improvements possible??
Posted: October 13th, 2011, 12:35 pm
by bbodine9
Thanks Den..I will have to look into SNS-HDR. Could you post a reworked version along with the original if you have the time? Thanks!
Re: Foggy picture...improvements possible??
Posted: October 13th, 2011, 12:57 pm
by den
To do these images any justice with improvements, you need to start from the RAW file or at the very least: full sized 100% quality jpegs. Starting images with the DPR posting resolution versions contain jpeg artifacts which will only get amplified... ...and this message board's posting requirements are such that they do not necessarily show in the illustration above...
...so unless a RAW file can be made available... ...there may not be much to learn here...
Re: Foggy picture...improvements possible??
Posted: October 14th, 2011, 1:27 pm
by den
Bruce... I just could not resist!
SNS-HDR Lite & PWP can be an incredible combination even with these low resolution jpegs.
The starting image:
- SF_Osprey-ori_400px.jpg (12.01 KiB) Viewed 6626 times
Workflow:
(1) The starting image processed with SNS-HDR Lite's 'default' preset
(2) The resulting(1) image noise reduced using PWP's BilateralSharpen with Amout 65; BR 5; BT 10; SF 20; ST 0
(3) a midtone range Composite-Blend at 67% Amount of the starting image and the resulting(2) image
- SF_Osprey-2_final_400px.jpg (20.54 KiB) Viewed 6625 times
The above workflow with minor changes specific to an image seems to be applicable to the other images in this series.
This image series seems to be taken generally where the sun was in front of the camera, so most images tend to be monochromatic... a challenging lighting situation for photographer and camera!!!
Re: Foggy picture...improvements possible??
Posted: October 14th, 2011, 2:05 pm
by Dieter Mayr
Here is the version with filtering the image with itself:
- SF_Osprey-1.JPG (21.92 KiB) Viewed 6622 times
Personally, I am not a big friend of too much HDR, for my taste the result of Den has too much of HDR, the fog above the ground comes out too pregnant for my taste.
But of course this is a very personal taste.
Re: Foggy picture...improvements possible??
Posted: October 14th, 2011, 8:00 pm
by bbodine9
Den and Dieter thanks for your posts, it is always good to see how different methods improve the photo. One's personal taste are always a factor.
Re: Foggy picture...improvements possible??
Posted: October 15th, 2011, 4:54 am
by tonygamble
Den,
"The resulting(1) image noise reduced using PWP's BilateralSharpen with Amout 65; BR 5; BT 10; SF 20; ST 0"
My SF only goes up to 5.
??
Tony
Re: Foggy picture...improvements possible??
Posted: October 15th, 2011, 10:30 am
by den
Thank you Tony... CORRECTION:
"The resulting(1) image noise reduced using PWP's BilateralSharpen with Amout 65; BR 5; BT 10; SF 0.20; ST 0"
Incidently, this use of the BilateralSharpen transform is also applicable for skin smoothing... vary the SF [usually between 0.20 and 0.70] and Amount to preference as needed for a specific image...
